Fluke 1630 Earth Ground Clamp Meter Description
The Fluke 1630 ground clamp meter uses a non-intrusive method in order to measure leakage current and test ground loops. This earth ground clamp meter uses the Stakeless testing system, which means that you do not need to disconnect ground rods, or find suitable locations for ground stakes. Using this method not only saves time, but also allows you to perform ground loop tests in locations where other techniques would not be viable. In addition, the device’s robust and portable design makes it ideal for any type of field work. We offer the Fluke 1630 to rent for just £65 per week.
Features and Benefits
- Wide ground loop resistance range
- Measures ground leakage current, without needing to disconnect
- Continuity loop test with audible alarm
- User-defined HI / LO Alarm limits for rapid measurement evaluation
- Automatic self calibration ensures correct measurement every time
Product Specs
- Operating error: Refers to the operating temperature range and is guaranteed for 2 years
- Storage temp. range: -20 °C to 60 °C (-4 °F to 140 °F )
- Reference temp. range: 23 °C ± 5 °C (73 °F ± 9 °F )
- Storage humidity: < 75 % RH
- Operating humidity: < 85 % RH
- Display: 9999 digit LC-display with special symbols
- Protection: IP20 according to IEC 529/EN 60529
- Safety: 300 V, CAT III / pollution degree 2 IEC 61010-1
- Weight: 640 g (1.4 lb)
- Conductor size: 35 mm (1.38 in) approximately
- Dimension (length x width x depth): 257 mm x 100 mm x 47 mm (1 in x 3.9 in x 1.9 in)
- Emission: IEC 1000 4-2, IEC 61326-1 class B
- Immunity: IEC 61000-4-2, 8 kV (air) criteria A, IEC 61000-4-3, 3 V/m performance criteria A
- Range selection: Auto
- Overload indicator: “OL” on display
- Measuring time: 0.4 sec
- Measuring frequency: 3.333 kHz
- Battery type: 9 V alkaline (type IEC 6 LR 61)
- Battery life: ≥ 8 hours (continuous operation)
- Power consumption: 40 mA
- Low battery indication: Display symbol
